Description

Technical Parameters

Scale (t/d)	Number of furnaces	Overall height of equipment (m)	Floor space (m²)	Emission standard
50	1	17	60	《Pollution control standards for household waste incineration》 (GB18485-2014)
100	1	17	75
150	2	17	90
200	2	17	105
250	3	17	12

If you are interested in our products, you can contact us directly.

Process charateristics

Simple structure ,easy installation and operation;
All equipment automation; Reduce the working load of the furnace personnel;
Low total building height and low construction cost;
The secondary combustion chamber adopts spiral dust removal structure and Tesla valve to reduce the fly ash content in the flue gas, reduce the subsequent dust removal cost, and extend the service life of the equipment.
The waste combustion is sufficient, and the heat burn reduction rate is less than 5%;
Pollutant emissions meet standards.
Customized complete proposal and turn-key WTE equipment.
